12mm F2.8 Full Frame Fisheye

+

The Rokinon 12mm F2.8 ED AS NCS Fish-eye Lens provides a 180º diagonal angle of view on full-frame cameras for an ultra-wide angle, distorted perspective that is useful for architectural interiors, landscapes and creative experimentation in any photographic application. The f/2.8 maximum aperture is effective in low light situations and enables some measure of shallow depth of field control.

The lens' sophisticated optical design consists of 12 lens elements arranged in 8 groups including three elements made of low dispersion ED glass and two aspherical lens elements to minimize coma and chromatic aberrations. Highly effective nanocrystal anti-reflection (NCS) coating applied together with UMC coatings improve light transmission and reduce ghosting. Its internal focus system enables its compact design and keeps the front element from extending during focus.

As a manual focus, manual aperture lens, it offers a wide, easy to grip focus ring and bright aperture, distance and depth of field markings. A removable petal-shaped lens hood is included.

  • An ultra wide-angle fisheye lens with a 12mm focal length on full-frame cameras and a 19.2mm equivalency when used on APS-C format cameras. Its distorted perspective is useful for interiors, landscapes, group shots and many creative wide-angle applications.
  • Extra low dispersion and aspherical lens elements reduce aberrations for sharp, color-accurate imaging.
  • Nano crystal coating and ultra multi-coating on the lens elements improves light transmission and reduces ghosting and flare.
  • Manual focus lens with an internal focus system and wide, rubberized focus ring.
  • Manual aperture control with bright markings for aperture, distance and depth of field.
  • Sturdy metal barrel with removable petal-shaped lens hood.

User Manual Download

Model name 12mm F2.8 FISH-EYE LENS
Aperture range F2.8 ~ 22
Lens optical construction 12 Elements in 8 Groups
Special lens 2 ASP
Minimum focusing distance 0.2m (0.66ft)
Filter size None
Maximum diameter Φ77.3mm / 3.04"
Mount Canon EF Nikon F with AE Pentax K Sony E
Angle of view Full Frame
180˚ 180˚ 180˚ 180˚
ASP-C 118˚ 124.6˚ 124.6˚ 124.6˚
FOUR-THIRDS
4/3”
- - - -
Length 72.7mm
2.86"
70.2mm
2.78"
71.2mm
2.80"
98.7mm
3.88"
Weight 515g
18.17oz
500g
17.64oz
505g
17.81oz
525g
18.52oz
Function A / S / M / P model (NIKON F with AE)

Model: 12M-C

UPC: 0-84438-76368-3

Focal Length: 12mm

Maximum Aperture: F2.8

Coverage: Full Frame (FX)

Optical Construction: 12 Glass Elements In 8 Groups

Aperture Range: F2.8 to F22

Diaphragm Blades: 7

Coating: Nano Coating System

Minimum Focusing Distance: 7.9”(0.20m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.04”(77.3mm)

Weight: 18.17oz (515g)

Length: 2.86” (72.7mm)

Model: 12M-N

UPC: 0-84438-76369-0

Focal Length: 12mm

Maximum Aperture: F2.8

Coverage: Full Frame (FX)

Optical Construction: 12 Glass Elements In 8 Groups

Aperture Range: F2.8 to F22

Diaphragm Blades: 7

Coating: Nano Coating System

Minimum Focusing Distance: 7.9”(0.20m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.04”(77.3mm)

Weight: 17.64oz (500g)

Length: 2.76” (70.2mm)

Model: 12M-P

UPC: 0-84438-76370-6

Focal Length: 12mm

Maximum Aperture: F2.8

Coverage: Full Frame (FX)

Optical Construction: 12 Glass Elements In 8 Groups

Aperture Range: F2.8 to F22

Diaphragm Blades: 7

Coating: Nano Coating System

Minimum Focusing Distance: 7.9”(0.20m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.04”(77.3mm)

Weight: 17.81oz (505g)

Length: 2.80” (71.2mm)

Model: 12M-E

UPC: 0-84438-76372-0

Focal Length: 12mm

Maximum Aperture: F2.8

Coverage: Full Frame (FX)

Optical Construction: 12 Glass Elements In 8 Groups

Aperture Range: F2.8 to F22

Diaphragm Blades: 7

Coating: Nano Coating System

Minimum Focusing Distance: 7.9”(0.20m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.04”(77.3mm)

Weight: 18.52oz (525g)

Length: 3.89” (98.6mm)

Specifications

Model name 12mm F2.8 FISH-EYE LENS
Aperture range F2.8 ~ 22
Lens optical construction 12 Elements in 8 Groups
Special lens 2 ASP
Minimum focusing distance 0.2m (0.66ft)
Filter size None
Maximum diameter Φ77.3mm / 3.04"
Mount Canon EF Nikon F with AE Pentax K Sony E
Angle of view Full Frame
180˚ 180˚ 180˚ 180˚
ASP-C 118˚ 124.6˚ 124.6˚ 124.6˚
FOUR-THIRDS
4/3”
- - - -
Length 72.7mm
2.86"
70.2mm
2.78"
71.2mm
2.80"
98.7mm
3.88"
Weight 515g
18.17oz
500g
17.64oz
505g
17.81oz
525g
18.52oz
Function A / S / M / P model (NIKON F with AE)

Canon EF

Model: 12M-C

UPC: 0-84438-76368-3

Focal Length: 12mm

Maximum Aperture: F2.8

Coverage: Full Frame (FX)

Optical Construction: 12 Glass Elements In 8 Groups

Aperture Range: F2.8 to F22

Diaphragm Blades: 7

Coating: Nano Coating System

Minimum Focusing Distance: 7.9”(0.20m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.04”(77.3mm)

Weight: 18.17oz (515g)

Length: 2.86” (72.7mm)

Nikon F with AE

Model: 12M-N

UPC: 0-84438-76369-0

Focal Length: 12mm

Maximum Aperture: F2.8

Coverage: Full Frame (FX)

Optical Construction: 12 Glass Elements In 8 Groups

Aperture Range: F2.8 to F22

Diaphragm Blades: 7

Coating: Nano Coating System

Minimum Focusing Distance: 7.9”(0.20m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.04”(77.3mm)

Weight: 17.64oz (500g)

Length: 2.76” (70.2mm)

Pentax K

Model: 12M-P

UPC: 0-84438-76370-6

Focal Length: 12mm

Maximum Aperture: F2.8

Coverage: Full Frame (FX)

Optical Construction: 12 Glass Elements In 8 Groups

Aperture Range: F2.8 to F22

Diaphragm Blades: 7

Coating: Nano Coating System

Minimum Focusing Distance: 7.9”(0.20m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.04”(77.3mm)

Weight: 17.81oz (505g)

Length: 2.80” (71.2mm)

Sony E

Model: 12M-E

UPC: 0-84438-76372-0

Focal Length: 12mm

Maximum Aperture: F2.8

Coverage: Full Frame (FX)

Optical Construction: 12 Glass Elements In 8 Groups

Aperture Range: F2.8 to F22

Diaphragm Blades: 7

Coating: Nano Coating System

Minimum Focusing Distance: 7.9”(0.20m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.04”(77.3mm)

Weight: 18.52oz (525g)

Length: 3.89” (98.6mm)
