$1,516.00

$2,046.00

16, 35, 50, 85mm Cine DS Lens Bundle

+

This Rokinon Bundle provides four lenses that you can use to shoot images from wide shots to portrait; it includes Rokinon's 16mm T2.2, 35mm T1.5, 50mm T1.5, and 85mm T1.5 Cine DS Lenses that feature sharp optics and similar physical characteristics for fast lens changes. The 16mm lens covers APS-C-sized sensors and features a maximum T-Stop of 2.2. The 35, 50, and 85mm lenses share a T-Stop range of 1.5 to 22 and cover full sized sensors.

Aperture and focus scales are marked on both sides of the lens, which makes it easier for a focus puller to work either side of the lens. The lenses feature a multi-layer coating providing good contrast, a sharp image, and protection from veiling glare. Industry standard focus and iris gear rings share a common position across the lenses for quick lens swaps when working with lens accessories such as follow focus units. Focus and iris are manual only with no electronic focus or iris control by the camera, and the iris ring is de-clicked, which allows you to make smooth iris pulls during a shot.

The Rokinon 16mm T2.2 VDLSR ED AS UMC CS II Lens is a wide-angle lens optimized for digital cinematography. The lens produces an image circle that will cover APS-C sized sensors or smaller. The focus and aperture rings feature industry-standard 0.8 pitch gearing for attaching a follow focus unit. The aperture ring is also de-clicked to allow for smooth iris pulls while shooting. Focus, aperture, and depth of field markings are on the side of the lens to aid focus pullers, who typically operates on the side of the camera.

The 16mm T2.2 lens is constructed out of 13 individual elements in 11 groups, including one aspherical and one hybrid aspherical element. Aspherical elements help minimize unwanted distortion and chromatic aberrations. The lens also has a multi-layer coating to reduce flares and maintain image contrast in bright conditions.

With an angle of view of 79.5°, the lens is well-suited for shooting landscapes, architecture, and for use in tight interior locations. A maximum aperture of T2.2 means that the lens is effective in low-light shooting and can produce a shallow depth of field when the lens is closer to the subject. The lens has a minimum focus distance of 7.87". A bayonet-mount lens hood and lens pouch come included with the lens.

  • 16mm lens with 79.5° angle-of-view
  • Image Circle covers APS-C sized sensors
  • Industry Standard 0.8 pitch gearing on Focus and Iris rings
  • De-clicked aperture for smooth focus pulls
  • 13 elements in 11 groups with an aspherical and a hybrid aspherical lens element
  • Ultra Multi Coating on lens minimizes flares and ghosting
  • Depth of Field markings on side of the lens
  • A minimum focusing distance of 7.87 inches
  • Includes bayonet mount lens hood
Specifications 16mm T2.2 ED AS UMC CS II
Aperture Range T2.2 ~ T22
Optical
Construction
13 ELEMENTS IN 11 GROUPS
(1 ASP &1 H-ASP)
Minimum
Focusing Distance
0.2m (0.66ft)
Filter Size 77.0mm
Maximum Diameter 83.0mm
Mount Nikon F Canon EF Sony E Micro 4/3
Angle Of View APS-C 83.1˚ 79.5˚ 83.1˚ -
FOUR-THIRDS
4/3”
- - - 67.6˚
Length (mm)
86.9mm 89.4mm 115.4mm 114.2mm
Weight (g) 580g 590g 620g 620g
Gear Module 0.8mm
A 7mm
B 4mm
C 43.8mm
D 8mm 10.5mm 36.5mm 35.3mm
Focus Ring Diameter 81.6mm
Aperture Ring Diameter 70.4mm 73.6mm



    The Rokinon 35mm T1.5 VDSLR AS UMC II Lens was developed primarily for film and video applications. The cine version of Rokinon's 35mm lens features industry-standard gearing for the focus and aperture ring, and the aperture ring has been de-clicked for smooth iris pulls. The aperture and focus scales have also been relocated to the side of the lens, where it is easier for focus pullers to read them.

    This lens is compatible with full-frame sensors and can also be used on APS-C-sized sensors, where the 35mm-equivalent focal length will be 56mm. The optical construction incorporates two high refractive index elements and one aspherical element to reduce chromatic aberrations and distortion to produce sharper imagery. Additionally, a UMC coating has been applied to lens elements to minimize lens flare and ghosting for more contrast-rich images.

    • Wide-angle prime lens is well-suited to use in a broad variety of shooting situations.
    • Fast T1.5 maximum aperture benefits working in low-light conditions and provides greater control over focus placement for shallow depth of field applications.
    • Two high refractive index elements and one aspherical element reduce chromatic aberrations in order to produce greater sharpness and clarity.
    • UMC coating improves light transmission and suppresses lens flare and ghosting for more contrast-rich, color-neutral images.
    • Geared aperture and focus rings are compatible with standard follow focuses for greater control over adjustment.
    • De-clicked aperture ring facilitates smooth, quiet exposure adjustments during recording.
    Specifications 35mm T1.5
    Aperture Range T1.5 ~ 22
    Optical
    Construction
    12 ELEMENTS IN 10 GROUPS
    (1 Aspherical, 1 High Refractive Index)
    Number of Blades 8
    Minimum
    Focusing Distance
    0.3m (12")
    Filter Size 77mm
    Maximum Diameter 83mm
    Mount Nikon F Canon EF Sony E Micro 4/3
    Angle Of View Full Frame 63.1˚ 63.1˚ 63.1˚ -
    ASP-C 43.2˚ 40.8˚ 43.2˚ -
    FOUR-THIRDS
    4/3”
    - - - 33.4˚
    Length (mm) 109mm 111.5mm 137.5mm 136.3mm
    Weight (g) 685g 700g 720g 770g
    Gear Module 0.8mm
    A 7mm
    B 4mm
    C 43.8mm
    D 8mm 10.5mm 36.5mm 35.3mm
    Focus Ring Diameter 81.6mm
    Aperture Ring Diameter 70.4mm 73.6mm



    The Rokinon 50mm T1.5 AS UMC Lens is a fast manual focus prime lens. It provides a very fast maximum aperture of T1.5 for effective low light capture and shallow depth of field control and an 8 blade iris for attractive bokeh. Optimized for cinema and video applications, the focus and aperture control rings are outfitted with industry standard gearing, which provides an interface for working with a traditional follow focus. The aperture control ring has also been de-clicked, which enables smooth iris pulls. In addition, bright aperture and distance markings are printed on the lens barrel facing laterally to facilitate easier control by a focus puller.

    The 50mm has a minimum focus distance of 1.5'. Internal focusing minimizes the effects of lens breathing, which insures a more consistent angle-of-view when adjusting focus. The lens is composed of 9 elements in 6 groups, including one aspherical element and one hybrid aspherical element to reduce aberrations. In addition, a lens multi-coating helps to improve light transmission reducing flare and ghosting. The filter thread diameter is 77mm.

    With this 50mm lens, Rokinon introduces the DS series of cinema lenses, unifying their cine lenses in more than just name. Each of the DS branded lenses will offer the same alignment of their geared focus and aperture rings so that follow focus and other rig accessories won't need re-adjustment when swapping lenses. Also, each DS lens is tested to be color matched with the other lenses in the series and provide the same color and contrast when shooting video. Lastly, the lenses are marked with focusing scales on each side of the barrel for easier adjustment from either side of the camera.

    • Standard length manual focus prime lens for EF mount cameras.
    • Functional as still photo lens but optimized for cinema and video shooting with geared aperture and focus rings, de-clicked aperture for smooth exposure transitions and laterally printed aperture and distance markings.
    • Very fast T1.5 maximum aperture for effective low light capture and shallow depth of field.
    • Internal focusing system with 9 lens elements in 6 groups.
    • One aspherical and one hybrid aspherical lens element control aberrations and improve sharpness throughout the frame.
    • Lens multi-coating improves light transmission and reduces flare and ghosting.
    • Minimum focus distance of 1.5'
    • Filter thread diameter of 77mm
    Specifications T1.5 50mm AS UMC II
    Aperture Range T1.5 ~ T22
    Optical
    Construction
    9 ELEMENTS IN 6 GROUPS
    (1 ASPHERICAL & 1 HYBRID LENS)
    Minimum
    Focusing Distance
    0.45m (1.47ft)
    Filter Size 77.0mm
    Maximum Diameter 81.6mm
    Mount Nikon F Canon EF Sony E Micro 4/3
    Angle Of View Full Frame
    46.2˚ 46.2˚ 46.2˚ -
    ASP-C 30.8˚ 29.0˚ 30.8˚ -
    FOUR-THIRDS
    4/3”
    - - - 23.6˚
    Length (mm)
    72.2mm 74.7mm 100.7mm 99.5mm
    Weight (g) 555g 575g 600g 590g
    Gear Module 0.8mm
    A 7mm
    B 4mm
    C 43.8mm
    D 8mm 10.5mm 36.5mm 35.3mm
    Focus Ring Diameter 81.6mm
    Aperture Ring Diameter 70.4mm 73.6mm



    The Rokinon 85mm T1.5 VDSLR AS IF UMC II Lens produces a slightly telephoto angle-of-view on full-frame sensors. It features a very fast maximum aperture of T1.5 and an 8 blade iris, for shallow depth of field with attractive bokeh. The focus and aperture control rings are outfitted with industry standard gearing, which provides an interface for working with a traditional follow focus. The aperture control ring has also been "declicked", which facilitates smooth iris pulls.

    The 85mm has a minimum focus distance of 3.6'. Internal focusing minimizes the effects of lens breathing, which insures a more consistent angle-of-view when adjusting focus. The lens is composed of 9 elements in 7 groups, including one aspherical element to reduce spherical aberrations. In addition, a multi-coated elements help improve light transmission.

    • 85mm focal length for full-frame format
    • Very fast T1.5 maximum aperture
    • 8 blade iris for attractive bokeh
    • Geared focus and aperture control rings
    • "Declicked" aperture control ring
    • Minimum focus distance of 3.6'
    • Internal focusing mitigates lens breathing
    • Aspheric lens element limits spherical aberration
    • Lens multi-coating improves transmission



    Specifications 85mm T1.5 VDSLR  AS IF UMC II
    Aperture Range T1.5 ~ T22
    Optical
    Construction
    9 ELEMENTS IN 7 GROUPS
    (1 ASPHERICAL LENS)
    Minimum
    Focusing Distance
    1.1m (3.6ft)
    Filter Size 72.0mm
    Maximum Diameter 78.0mm
    Mount Nikon F Canon EF Sony E Micro 4/3
    Angle Of View Full Frame
    28.3˚ 28.3˚ 28.3˚ -
    ASP-C 19.1˚ 17.7˚ 19.1˚ -
    FOUR-THIRDS
    4/3”
    - - - 14.4˚
    Length (mm)
    72.2mm 74.7mm 100.7mm 99.5mm
    Weight (g) 560g 580g 605g 595g
    Gear Module 0.8mm
    A 7mm
    B 4mm
    C 43.8mm
    D 8mm 10.5mm 36.5mm 35.3mm
    Focus Ring Diameter 81.6mm
    Aperture Ring Diameter 70.4mm 73.6mm

    16mm T2.2 High Speed Wide Angle

    The Rokinon 16mm T2.2 VDLSR ED AS UMC CS II Lens is a wide-angle lens optimized for digital cinematography. The lens produces an image circle that will cover APS-C sized sensors or smaller. The focus and aperture rings feature industry-standard 0.8 pitch gearing for attaching a follow focus unit. The aperture ring is also de-clicked to allow for smooth iris pulls while shooting. Focus, aperture, and depth of field markings are on the side of the lens to aid focus pullers, who typically operates on the side of the camera.

    The 16mm T2.2 lens is constructed out of 13 individual elements in 11 groups, including one aspherical and one hybrid aspherical element. Aspherical elements help minimize unwanted distortion and chromatic aberrations. The lens also has a multi-layer coating to reduce flares and maintain image contrast in bright conditions.

    With an angle of view of 79.5°, the lens is well-suited for shooting landscapes, architecture, and for use in tight interior locations. A maximum aperture of T2.2 means that the lens is effective in low-light shooting and can produce a shallow depth of field when the lens is closer to the subject. The lens has a minimum focus distance of 7.87". A bayonet-mount lens hood and lens pouch come included with the lens.

    • 16mm lens with 79.5° angle-of-view
    • Image Circle covers APS-C sized sensors
    • Industry Standard 0.8 pitch gearing on Focus and Iris rings
    • De-clicked aperture for smooth focus pulls
    • 13 elements in 11 groups with an aspherical and a hybrid aspherical lens element
    • Ultra Multi Coating on lens minimizes flares and ghosting
    • Depth of Field markings on side of the lens
    • A minimum focusing distance of 7.87 inches
    • Includes bayonet mount lens hood
    Specifications 16mm T2.2 ED AS UMC CS II
    Aperture Range T2.2 ~ T22
    Optical
    Construction
    13 ELEMENTS IN 11 GROUPS
    (1 ASP &1 H-ASP)
    Minimum
    Focusing Distance
    0.2m (0.66ft)
    Filter Size 77.0mm
    Maximum Diameter 83.0mm
    Mount Nikon F Canon EF Sony E Micro 4/3
    Angle Of View APS-C 83.1˚ 79.5˚ 83.1˚ -
    FOUR-THIRDS
    4/3”
    - - - 67.6˚
    Length (mm)
    86.9mm 89.4mm 115.4mm 114.2mm
    Weight (g) 580g 590g 620g 620g
    Gear Module 0.8mm
    A 7mm
    B 4mm
    C 43.8mm
    D 8mm 10.5mm 36.5mm 35.3mm
    Focus Ring Diameter 81.6mm
    Aperture Ring Diameter 70.4mm 73.6mm



      35mm T1.5 Full Frame Wide Angle

      The Rokinon 35mm T1.5 VDSLR AS UMC II Lens was developed primarily for film and video applications. The cine version of Rokinon's 35mm lens features industry-standard gearing for the focus and aperture ring, and the aperture ring has been de-clicked for smooth iris pulls. The aperture and focus scales have also been relocated to the side of the lens, where it is easier for focus pullers to read them.

      This lens is compatible with full-frame sensors and can also be used on APS-C-sized sensors, where the 35mm-equivalent focal length will be 56mm. The optical construction incorporates two high refractive index elements and one aspherical element to reduce chromatic aberrations and distortion to produce sharper imagery. Additionally, a UMC coating has been applied to lens elements to minimize lens flare and ghosting for more contrast-rich images.

      • Wide-angle prime lens is well-suited to use in a broad variety of shooting situations.
      • Fast T1.5 maximum aperture benefits working in low-light conditions and provides greater control over focus placement for shallow depth of field applications.
      • Two high refractive index elements and one aspherical element reduce chromatic aberrations in order to produce greater sharpness and clarity.
      • UMC coating improves light transmission and suppresses lens flare and ghosting for more contrast-rich, color-neutral images.
      • Geared aperture and focus rings are compatible with standard follow focuses for greater control over adjustment.
      • De-clicked aperture ring facilitates smooth, quiet exposure adjustments during recording.
      Specifications 35mm T1.5
      Aperture Range T1.5 ~ 22
      Optical
      Construction
      12 ELEMENTS IN 10 GROUPS
      (1 Aspherical, 1 High Refractive Index)
      Number of Blades 8
      Minimum
      Focusing Distance
      0.3m (12")
      Filter Size 77mm
      Maximum Diameter 83mm
      Mount Nikon F Canon EF Sony E Micro 4/3
      Angle Of View Full Frame 63.1˚ 63.1˚ 63.1˚ -
      ASP-C 43.2˚ 40.8˚ 43.2˚ -
      FOUR-THIRDS
      4/3”
      - - - 33.4˚
      Length (mm) 109mm 111.5mm 137.5mm 136.3mm
      Weight (g) 685g 700g 720g 770g
      Gear Module 0.8mm
      A 7mm
      B 4mm
      C 43.8mm
      D 8mm 10.5mm 36.5mm 35.3mm
      Focus Ring Diameter 81.6mm
      Aperture Ring Diameter 70.4mm 73.6mm



      50mm T1.5 Full Frame

      The Rokinon 50mm T1.5 AS UMC Lens is a fast manual focus prime lens. It provides a very fast maximum aperture of T1.5 for effective low light capture and shallow depth of field control and an 8 blade iris for attractive bokeh. Optimized for cinema and video applications, the focus and aperture control rings are outfitted with industry standard gearing, which provides an interface for working with a traditional follow focus. The aperture control ring has also been de-clicked, which enables smooth iris pulls. In addition, bright aperture and distance markings are printed on the lens barrel facing laterally to facilitate easier control by a focus puller.

      The 50mm has a minimum focus distance of 1.5'. Internal focusing minimizes the effects of lens breathing, which insures a more consistent angle-of-view when adjusting focus. The lens is composed of 9 elements in 6 groups, including one aspherical element and one hybrid aspherical element to reduce aberrations. In addition, a lens multi-coating helps to improve light transmission reducing flare and ghosting. The filter thread diameter is 77mm.

      With this 50mm lens, Rokinon introduces the DS series of cinema lenses, unifying their cine lenses in more than just name. Each of the DS branded lenses will offer the same alignment of their geared focus and aperture rings so that follow focus and other rig accessories won't need re-adjustment when swapping lenses. Also, each DS lens is tested to be color matched with the other lenses in the series and provide the same color and contrast when shooting video. Lastly, the lenses are marked with focusing scales on each side of the barrel for easier adjustment from either side of the camera.

      • Standard length manual focus prime lens for EF mount cameras.
      • Functional as still photo lens but optimized for cinema and video shooting with geared aperture and focus rings, de-clicked aperture for smooth exposure transitions and laterally printed aperture and distance markings.
      • Very fast T1.5 maximum aperture for effective low light capture and shallow depth of field.
      • Internal focusing system with 9 lens elements in 6 groups.
      • One aspherical and one hybrid aspherical lens element control aberrations and improve sharpness throughout the frame.
      • Lens multi-coating improves light transmission and reduces flare and ghosting.
      • Minimum focus distance of 1.5'
      • Filter thread diameter of 77mm
      Specifications T1.5 50mm AS UMC II
      Aperture Range T1.5 ~ T22
      Optical
      Construction
      9 ELEMENTS IN 6 GROUPS
      (1 ASPHERICAL & 1 HYBRID LENS)
      Minimum
      Focusing Distance
      0.45m (1.47ft)
      Filter Size 77.0mm
      Maximum Diameter 81.6mm
      Mount Nikon F Canon EF Sony E Micro 4/3
      Angle Of View Full Frame
      46.2˚ 46.2˚ 46.2˚ -
      ASP-C 30.8˚ 29.0˚ 30.8˚ -
      FOUR-THIRDS
      4/3”
      - - - 23.6˚
      Length (mm)
      72.2mm 74.7mm 100.7mm 99.5mm
      Weight (g) 555g 575g 600g 590g
      Gear Module 0.8mm
      A 7mm
      B 4mm
      C 43.8mm
      D 8mm 10.5mm 36.5mm 35.3mm
      Focus Ring Diameter 81.6mm
      Aperture Ring Diameter 70.4mm 73.6mm



      85mm T1.5 Full Frame

      The Rokinon 85mm T1.5 VDSLR AS IF UMC II Lens produces a slightly telephoto angle-of-view on full-frame sensors. It features a very fast maximum aperture of T1.5 and an 8 blade iris, for shallow depth of field with attractive bokeh. The focus and aperture control rings are outfitted with industry standard gearing, which provides an interface for working with a traditional follow focus. The aperture control ring has also been "declicked", which facilitates smooth iris pulls.

      The 85mm has a minimum focus distance of 3.6'. Internal focusing minimizes the effects of lens breathing, which insures a more consistent angle-of-view when adjusting focus. The lens is composed of 9 elements in 7 groups, including one aspherical element to reduce spherical aberrations. In addition, a multi-coated elements help improve light transmission.

      • 85mm focal length for full-frame format
      • Very fast T1.5 maximum aperture
      • 8 blade iris for attractive bokeh
      • Geared focus and aperture control rings
      • "Declicked" aperture control ring
      • Minimum focus distance of 3.6'
      • Internal focusing mitigates lens breathing
      • Aspheric lens element limits spherical aberration
      • Lens multi-coating improves transmission



      Specifications 85mm T1.5 VDSLR  AS IF UMC II
      Aperture Range T1.5 ~ T22
      Optical
      Construction
      9 ELEMENTS IN 7 GROUPS
      (1 ASPHERICAL LENS)
      Minimum
      Focusing Distance
      1.1m (3.6ft)
      Filter Size 72.0mm
      Maximum Diameter 78.0mm
      Mount Nikon F Canon EF Sony E Micro 4/3
      Angle Of View Full Frame
      28.3˚ 28.3˚ 28.3˚ -
      ASP-C 19.1˚ 17.7˚ 19.1˚ -
      FOUR-THIRDS
      4/3”
      - - - 14.4˚
      Length (mm)
      72.2mm 74.7mm 100.7mm 99.5mm
      Weight (g) 560g 580g 605g 595g
      Gear Module 0.8mm
      A 7mm
      B 4mm
      C 43.8mm
      D 8mm 10.5mm 36.5mm 35.3mm
      Focus Ring Diameter 81.6mm
      Aperture Ring Diameter 70.4mm 73.6mm
