$319.00

16mm F2.0 High Speed Wide Angle

+

The 16mm f/2.0 ED AS UMC CS Lens from Rokinon is a manual focus wide-angle lens compatible with APS-C format DSLR digital cameras. It provides a 79.5° angle of view which translates into a 35mm format equivalency of 25.6mm. A fast maximum aperture of f/2.0 is effective in low light shooting and provides shallow depth of field. With two aspherical lens elements and one extra-low dispersion element, chromatic aberrations are minimized and sharp, color-accurate images are the result. UMC lens coating facilitates even light transmission and reduces ghosting and flare.

  • Wide angle focal length equivalent to 25.6mm in the 35mm format
    • Fast f/2.0 maximum aperture for effective low light shooting and shallow depth of field
    • Aspherical and Extra-low Dispersion lens elements reduce aberrations
      • UMC lens coating allows even light transmission and minimizes ghosting and flare

      User Manual Download

      SPECIFICATIONS 1:2.0 16mm ED AS UMC CS
      APERTURE RANGE F2.0 ~ 22
      OPTICAL
      CONSTRUCTION
      13 ELEMENTS IN 11 GROUPS
      MINIMUM
      FOCUSING DISTANCE
      0.2m (0.66ft)
      FILTER SIZE Φ77mm
      MAXIMUM DIAMETER Φ83mm
      MOUNT Canon EF Nikon F with
      AE
      Pentax K Canon M Fujifilm X Sony E Micro 4/3
      ANGLE OF VIEW ASP-C 75.9˚ 83.1˚ 83.1˚ 79.5˚ 83.1˚ 83.1˚ -
      FOUR-THIRDS
      4/3”
      - - - - - - 67.6˚
      LENGTH (mm) 89.4mm 86.9mm 87.9mm 115.3mm 115.7mm 115.4mm 114.2mm
      WEIGHT (g) 585g 570g 575g 615g 615g 615g 610g
      FUNCTION A / S / M / P mode (NIKON F with AE)

      Model: 16M-P

      UPC: 0-84438-76130-6

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 3.46” (87.9mm)

      Model: 16M-FX

      UPC: 0-84438-76134-4

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 4.56” (115.7mm)

      Model: 16M-E

      UPC: 0-84438-76132-0

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 4.54” (115.4mm)

      Model: 16M-M43

      UPC: 0-84438-76131-3

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 4.50” (114.2mm)

      Model: 16M-M

      UPC: 0-84438-76135-1

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 21.69oz (615g)

      Length: 4.54” (115.4mm)

      Model: 16M-C

      UPC: 0-84438-76127-6

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 3.52" (89.4mm)

      Model: 16MAF-N

      UPC: 0-84438-76128-3

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 3.42" (86.9mm)

      Specifications

      SPECIFICATIONS 1:2.0 16mm ED AS UMC CS
      APERTURE RANGE F2.0 ~ 22
      OPTICAL
      CONSTRUCTION
      13 ELEMENTS IN 11 GROUPS
      MINIMUM
      FOCUSING DISTANCE
      0.2m (0.66ft)
      FILTER SIZE Φ77mm
      MAXIMUM DIAMETER Φ83mm
      MOUNT Canon EF Nikon F with
      AE
      Pentax K Canon M Fujifilm X Sony E Micro 4/3
      ANGLE OF VIEW ASP-C 75.9˚ 83.1˚ 83.1˚ 79.5˚ 83.1˚ 83.1˚ -
      FOUR-THIRDS
      4/3”
      - - - - - - 67.6˚
      LENGTH (mm) 89.4mm 86.9mm 87.9mm 115.3mm 115.7mm 115.4mm 114.2mm
      WEIGHT (g) 585g 570g 575g 615g 615g 615g 610g
      FUNCTION A / S / M / P mode (NIKON F with AE)

      Pentax K

      Model: 16M-P

      UPC: 0-84438-76130-6

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 3.46” (87.9mm)

      Fuji X

      Model: 16M-FX

      UPC: 0-84438-76134-4

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 4.56” (115.7mm)

      Sony E

      Model: 16M-E

      UPC: 0-84438-76132-0

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 4.54” (115.4mm)

      Micro 4/3

      Model: 16M-M43

      UPC: 0-84438-76131-3

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 4.50” (114.2mm)

      Canon M

      Model: 16M-M

      UPC: 0-84438-76135-1

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 21.69oz (615g)

      Length: 4.54” (115.4mm)

      Canon EF

      Model: 16M-C

      UPC: 0-84438-76127-6

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 3.52" (89.4mm)

      Nikon F with AE

      Model: 16MAF-N

      UPC: 0-84438-76128-3

      Focal Length: 16mm

      Maximum Aperture: F2.0

      Coverage: APS-C/Four Thirds

      Optical Construction: 13 Glass Elements In 11 Groups

      Aperture Range: F2.0 to F22

      Diaphragm Blades: 8

      Coating: Ultra Multi-Coating

      Minimum Focusing Distance: 7.9” (0.2m)

      Filter Size: 77mm

      Lens Hood: Removable Petal Shaped

      Maximum Diameter: 3.27”(83mm)

      Weight: 25.04oz (710g)

      Length: 3.42" (86.9mm)
