$349.00

16mm T2.2 High Speed Wide Angle Cine DS

+

The Rokinon 16mm T2.2 VDLSR ED AS UMC CS II Lens is a wide-angle lens optimized for digital cinematography. The lens produces an image circle that will cover APS-C sized sensors or smaller. The focus and aperture rings feature industry-standard 0.8 pitch gearing for attaching a follow focus unit. The aperture ring is also de-clicked to allow for smooth iris pulls while shooting. Focus, aperture, and depth of field markings are on the side of the lens to aid focus pullers, who typically operates on the side of the camera.

The 16mm T2.2 lens is constructed out of 13 individual elements in 11 groups, including one aspherical and one hybrid aspherical element. Aspherical elements help minimize unwanted distortion and chromatic aberrations. The lens also has a multi-layer coating to reduce flares and maintain image contrast in bright conditions.

With an angle of view of 79.5°, the lens is well-suited for shooting landscapes, architecture, and for use in tight interior locations. A maximum aperture of T2.2 means that the lens is effective in low-light shooting and can produce a shallow depth of field when the lens is closer to the subject. The lens has a minimum focus distance of 7.87". A bayonet-mount lens hood and lens pouch come included with the lens.

  • 16mm lens with 79.5° angle-of-view
  • Image Circle covers APS-C sized sensors
  • Industry Standard 0.8 pitch gearing on Focus and Iris rings
  • De-clicked aperture for smooth focus pulls
  • 13 elements in 11 groups with an aspherical and a hybrid aspherical lens element
  • Ultra Multi Coating on lens minimizes flares and ghosting
  • Depth of Field markings on side of the lens
  • A minimum focusing distance of 7.87 inches
  • Includes bayonet mount lens hood

User Manual Download

Specifications 16mm T2.2 ED AS UMC CS II
Aperture Range T2.2 ~ T22
Optical
Construction
13 ELEMENTS IN 11 GROUPS
(1 ASP &1 H-ASP)
Minimum
Focusing Distance
0.2m (0.66ft)
Filter Size 77.0mm
Maximum Diameter 83.0mm
Mount Nikon F Canon EF Sony E Micro 4/3
Angle Of View APS-C 83.1˚ 79.5˚ 83.1˚ -
FOUR-THIRDS
4/3”
- - - 67.6˚
Length (mm)
86.9mm 89.4mm 115.4mm 114.2mm
Weight (g) 580g 590g 620g 620g
Gear Module 0.8mm
A 7mm
B 4mm
C 43.8mm
D 8mm 10.5mm 36.5mm 35.3mm
Focus Ring Diameter 81.6mm
Aperture Ring Diameter 70.4mm 73.6mm

Model: DS16M-C

UPC: 0-84438-76383-6

Focal Length: 16mm

Maximum Aperture: T2.2

Coverage: APS-C/Four Thirds

Optical Construction: 13 Glass Elements In 11 Groups

Aperture Range: T2.2 to T22

Diaphragm Blades: 8

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 7.9” (0.20m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27” (83mm)

Weight: 20.8oz (590g)

Length: 3.52” (89.4mm)

Model: DS16M-N

UPC: 0-84438-76385-0

Focal Length: 16mm

Maximum Aperture: T2.2

Coverage: APS-C/Four Thirds

Optical Construction: 13 Glass Elements In 11 Groups

Aperture Range: T2.2 to T22

Diaphragm Blades: 8

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 7.9” (0.20m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27” (83mm)

Weight: 20.5oz (580g)

Length: 3.42” (86.9mm)

Model: DS16M-NEX

UPC: 0-84438-76386-7

Focal Length: 16mm

Maximum Aperture: T2.2

Coverage: APS-C/Four Thirds

Optical Construction: 13 Glass Elements In 11 Groups

Aperture Range: T2.2 to T22

Diaphragm Blades: 8

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 7.9” (0.20m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27” (83mm)

Weight: 21.9oz (620g)

Length: 4.54” (115.4mm)

Model: DS16M-MFT

UPC: 0-84438-76384-3

Focal Length: 16mm

Maximum Aperture: T2.2

Coverage: APS-C/Four Thirds

Optical Construction: 13 Glass Elements In 11 Groups

Aperture Range: T2.2 to T22

Diaphragm Blades: 8

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 7.9” (0.20m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27” (83mm)

Weight: 21.9oz (620g)

Length: 4.49” (114.2mm)

Specifications

Specifications 16mm T2.2 ED AS UMC CS II
Aperture Range T2.2 ~ T22
Optical
Construction
13 ELEMENTS IN 11 GROUPS
(1 ASP &1 H-ASP)
Minimum
Focusing Distance
0.2m (0.66ft)
Filter Size 77.0mm
Maximum Diameter 83.0mm
Mount Nikon F Canon EF Sony E Micro 4/3
Angle Of View APS-C 83.1˚ 79.5˚ 83.1˚ -
FOUR-THIRDS
4/3”
- - - 67.6˚
Length (mm)
86.9mm 89.4mm 115.4mm 114.2mm
Weight (g) 580g 590g 620g 620g
Gear Module 0.8mm
A 7mm
B 4mm
C 43.8mm
D 8mm 10.5mm 36.5mm 35.3mm
Focus Ring Diameter 81.6mm
Aperture Ring Diameter 70.4mm 73.6mm

Canon EF

Model: DS16M-C

UPC: 0-84438-76383-6

Focal Length: 16mm

Maximum Aperture: T2.2

Coverage: APS-C/Four Thirds

Optical Construction: 13 Glass Elements In 11 Groups

Aperture Range: T2.2 to T22

Diaphragm Blades: 8

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 7.9” (0.20m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27” (83mm)

Weight: 20.8oz (590g)

Length: 3.52” (89.4mm)

Nikon F

Model: DS16M-N

UPC: 0-84438-76385-0

Focal Length: 16mm

Maximum Aperture: T2.2

Coverage: APS-C/Four Thirds

Optical Construction: 13 Glass Elements In 11 Groups

Aperture Range: T2.2 to T22

Diaphragm Blades: 8

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 7.9” (0.20m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27” (83mm)

Weight: 20.5oz (580g)

Length: 3.42” (86.9mm)

Sony E

Model: DS16M-NEX

UPC: 0-84438-76386-7

Focal Length: 16mm

Maximum Aperture: T2.2

Coverage: APS-C/Four Thirds

Optical Construction: 13 Glass Elements In 11 Groups

Aperture Range: T2.2 to T22

Diaphragm Blades: 8

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 7.9” (0.20m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27” (83mm)

Weight: 21.9oz (620g)

Length: 4.54” (115.4mm)

Micro 4/3

Model: DS16M-MFT

UPC: 0-84438-76384-3

Focal Length: 16mm

Maximum Aperture: T2.2

Coverage: APS-C/Four Thirds

Optical Construction: 13 Glass Elements In 11 Groups

Aperture Range: T2.2 to T22

Diaphragm Blades: 8

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 7.9” (0.20m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27” (83mm)

Weight: 21.9oz (620g)

Length: 4.49” (114.2mm)
