16mm T2.6 Ultra Wide Angle XEEN Pro Cinema Lens - Rokinon
16mm T2.6 Ultra Wide Angle XEEN Pro Cinema Lens - Rokinon
16mm T2.6 Ultra Wide Angle XEEN Pro Cinema Lens - Rokinon
$1,595.00

16mm T2.6 Ultra Wide Angle XEEN Pro Cinema Lens

+

Rokinon's Xeen 16mm T2.6 Lens is built specifically for use as a cinema lens. It features an internal focus design so that the lens does not change size while focusing, minimizing the appearance of breathing when changing focus. Each lens in the set is multi-coated for good contrast, glare prevention, and color-match to a factory standard, allowing you to assemble a set over time with minimal color shift. This 16mm lens provides what is considered a very wide angle of view on full-frame cameras, and a tighter angle of view on smaller formats.

The lens features dual sided focus scales marked in feet, with dual-sided iris scales. The 11-bladed iris provides a rounded aperture for natural looking highlights and bokeh. The lens is a manual focus and iris lens, and does not have auto focus or auto iris capability. It incorporates cinema-style focus and iris gears that share the same position across the lenses in the Xeen set. The common 114mm front diameter allows for quick lens changes when using a matte box and focus accessories. The focus ring rotates 200° from close focus to infinity. This gives you a high degree of precision when adjusting focus.

  • This 16mm lens has an image circle that covers a full-frame sensor
  • The lens features metal construction and it incorporates a support that can help take strain off your camera's lens port
  • Dual right and left side focus and t-stop scales allow your focus puller to work from either side of the lens
  • Each lens in the XEEN series share common focus and iris gear ring positions
  • The common 114mm front diameter allows for quick lens changes
  • The non-rotating front allows you to use optional clip-on matte boxes
  • Clickless aperture ring for smooth iris pulls
  • A minimum focusing distance of 11.8" allows you to get up close to your subject
  • 6K Ready Optics
  • Full Frame Coverage
  • Tightly Color Matched
  • Durable All Metal Body
  • Unified 40° Iris Rotation
  • Unified 200° Focus Throw
  • Large Easy To Read Markings
  • Three Year Limited Warranty
  • Lens Support Mount (Except PL)
  • Xeen Proprietary X-Coating Technology
  • Unified 114mm Non-Rotating Front Diameters
  • 11 Bladed Diaphragm for Superb Bokeh
  • Unified Focus and Aperture Gear Positions for Easy Follow Focus Use
  • Mounts can be shimmed and are interchangeable by a qualified technician
  • Incredibly smooth and fully damped movement of focusing and aperture controls

User Manual Download

Focal length 16mm
Maximum T-stop T2.6
Negative size 24 mm X 36 mm
Angle of view Full Frame(1:1x) 106.91˚
Super 35 87.43˚
APS-C (1:1.5x) 82.02˚
APS-C (1:1.6x) 79.85˚
MFT (1:2x) 66.86˚
Focusing range ∞ to 0.30 m
Front size Φ114mm
Number of blades 11
Size PL Φ117.6mm x 87.3mm
Canon EF Φ117.6mm x 95.3mm
Nikon F Φ117.6mm x 92.8mm
Sony E Φ117.6mm x 121.3mm
MFT Φ117.6mm x 120.1mm
Angle Focus angle 200°
Iris angle 32.5°
Weight
(without Lens cap)
PL 1,175g
Canon EF 1,175g
Nikon F 1,130g
Sony E 1,180g
MFT 1,180g

Model: XN16-C

UPC: 084438765496

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 41.45oz (1,175g)

Length: 3.75” (95.3mm)

Model: XN16-N

UPC: 0844387655519

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 39.86oz (1,130g)

Length: 3.65” (92.8mm)

Model: XN16-NEX

UPC: 084438765526

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 41.62oz (1,180g)

Length: 4.78” (121.3mm)

Model: XN16-PL

UPC: 084438765533

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 41.45oz (1,175g)

Length: 3.44” (87.3mm)

Model: XN16-MFT

UPC: 084438765502

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 41.62oz (1,180g)

Length: 4.73” (120.1mm)

Specifications

Focal length 16mm
Maximum T-stop T2.6
Negative size 24 mm X 36 mm
Angle of view Full Frame(1:1x) 106.91˚
Super 35 87.43˚
APS-C (1:1.5x) 82.02˚
APS-C (1:1.6x) 79.85˚
MFT (1:2x) 66.86˚
Focusing range ∞ to 0.30 m
Front size Φ114mm
Number of blades 11
Size PL Φ117.6mm x 87.3mm
Canon EF Φ117.6mm x 95.3mm
Nikon F Φ117.6mm x 92.8mm
Sony E Φ117.6mm x 121.3mm
MFT Φ117.6mm x 120.1mm
Angle Focus angle 200°
Iris angle 32.5°
Weight
(without Lens cap)
PL 1,175g
Canon EF 1,175g
Nikon F 1,130g
Sony E 1,180g
MFT 1,180g

Canon EF

Model: XN16-C

UPC: 084438765496

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 41.45oz (1,175g)

Length: 3.75” (95.3mm)

Nikon F

Model: XN16-N

UPC: 0844387655519

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 39.86oz (1,130g)

Length: 3.65” (92.8mm)

Sony E

Model: XN16-NEX

UPC: 084438765526

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 41.62oz (1,180g)

Length: 4.78” (121.3mm)

PL

Model: XN16-PL

UPC: 084438765533

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 41.45oz (1,175g)

Length: 3.44” (87.3mm)

Micro 4/3

Model: XN16-MFT

UPC: 084438765502

Focal Length: 16mm

Maximum Aperture: T2.6

Coverage: Full Frame (FX)

Aperture Range: T2.6 to T22

Diaphragm Blades: 11

Coating: XEEN X-Coating Technology

Minimum Focusing Distance: 11.8" (.30m)

Filter Size: 114mm Front Diameter sized for use with Standard 114mm Matte Boxes

Lens Hood: Built-In

Maximum Diameter: 4.6" (117.6mm)

Weight: 41.62oz (1,180g)

Length: 4.73” (120.1mm)
