20mm T1.9 Full Frame Wide Angle Cine DS

DS20M-C

Regular price $699.00 Sale price$449.00
/
Shipping calculated at checkout.
Mount

Model: DS20M-C

UPC: 0-84438-76536-6

Focal Length: 20mm

Coverage: Full Frame

Optical Construction: 13 Glass Element 12 Groups

Aperture Range: T1.9 to T22

Diaphragm Blades: 7

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 0.65ft (0.2m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27" (83mm)

Weight: 21.7oz (615g)

Length: 3.84" (97.5mm)

Model: DS20M-MFT

UPC: 0-84438-76537-3

Focal Length: 20mm

Coverage: Full Frame

Optical Construction: 13 Glass Element 12 Groups

Aperture Range: T1.9 to T22

Diaphragm Blades: 7

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 0.65ft (0.2m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27" (83mm)

Weight: 22.4oz (635g)

Length: 4.82" (122.3mm)

Model: DS20M-N

UPC: 0-84438-76538-0

Focal Length: 20mm

Coverage: Full Frame

Optical Construction: 13 Glass Element 12 Groups

Aperture Range: T1.9 to T22

Diaphragm Blades: 7

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 0.65ft (0.2m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27" (83mm)

Weight: 3.66" (95mm)

Length: 21.2oz (600g)

Model: DS20M-NEX

UPC: 0-84438-76539-7

Focal Length: 20mm

Coverage: Full Frame

Optical Construction: 13 Glass Element 12 Groups

Aperture Range: T1.9 to T22

Diaphragm Blades: 7

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 0.65ft (0.2m)

Filter Size: 77mm

Lens Hood: Removable Petal Shaped

Maximum Diameter: 3.27" (83mm)

Weight: 22.6oz (640g)

Length: 4.86" (123.5mm)

※ This product image is a Canon EF mount lens. Size and design may vary depending on the mount of a lens

Utilizing a multi-layer coating process for consistent color rendition from lens to lens the Rokinon 20mm T1.9 Cine DS Lens answers the challenge of assembling a set of lenses over time. This features industry standard geared focus and iris rings that share common position with other Rokinon Cine DS lenses. To aid focus pullers who have to work both sides of the lens, the aperture and focus scales are marked on both sides of the lens.

This 20mm lens produces 94.8° angle of view when used with full-frame cameras. Hybrid aspherical lenses render sharply defined images with a minimum of distortion and chromatic aberrations, with a minimum focus distance of just under 8" from the lens. A removable petal shaped lens hood provides flare protection when shooting without a matte box, the lenses threaded front accepts a 77mm filter ring.

  • 20mm lens with a 94.8° angle of view when used with full-frame cameras.
  • Ultra Multi Coated lenses minimize flare and ghosting, and the lenses are color matched to a standard eliminating the need to acquire an entire set of lenses at the same time.
  • Industry-standard gearing for focus and aperture rings. Each lens in the Rokinon DS series share common focus and iris gear ring positions, which speeds up lens changes as accessories such as follow focus units or iris motors don't have to be re-positioned.
  • Clickless aperture ring for smooth iris pulls.
  • A minimum focusing distance of 7.8" allows you to get up close to your subject.
  • A removable petal-type lens hood provides flare protection without a matte box.

User Manual Download

Specifications

Specifications20mm T1.9 ED AS UMC
Aperture RangeT1.9 ~ 22
Optical Construction13 Elements in 12 Groups
Minimum Focusing Distance0.2m (0.65ft)
Filter Size77.0mm
Maximum Diameter83.0mm
MountNikon FCanon EFSony EMFT
Angle of View35mm94.8˚94.8˚94.8˚-
APS-C66.9˚70.3˚70.3˚-
Four-Thirds (4/3”)---56.1˚
Length (mm)85.9mm88.4mm114.4mm113.2mm
Weight (g)508g518g546g541g
GearModule0.8mm
A7mm
B4mm
C43.8mm
D8mm10.5mm36.5mm35.3mm
Focus Ring Diameter81.6mm
Aperture Ring Diameter70.4mm73.6mm

MTF Chart

Optical Construction

De-clicked aperture and calibrated in T-stops

Apertures are de-clicked for precise, smooth and silent operation. Calibrated in T-stops to provide accurate and consistent exposure.

Industry-standard gearing for focus and aperture rings

Each lens in the Rokinon DS series shares common focus and iris gear ring positions, which speeds up lens changes as accessories such as follow focus units or iris motors don't have to be re-positioned.

Dual sided lens markings

To aid focus pullers who have to work both sides of the lens, the aperture and focus scales are marked on both sides of the lens.
