$579.00

24mm T1.5 Full Frame Wide Angle Cine DSX

+

Boasting a new compact and sleek design with matte black finish, ROKINON CINE DSX lenses offer additional welcome features including a rounded nine blade aperture for even smoother circular bokeh.

Lens mounts are now weather sealed, and Cine DSX lenses are even available in Canon RF mount. In addition, DSX lenses are fully compatible in terms of color rendition and gear placement with ROKINON CINE DS lenses.

With full frame coverage, fast apertures, and optical designs utilizing special elements, DSX lenses support the increased capabilities of the latest DSLR, Mirrorless, Cine camera systems, and drones. ROKINON CINE DSX lenses are the perfect choice for independent filmmakers, project directors, and professional cinematographers.

ROKINON CINE LENS FEATURES

  • Calibration in T-stops
  • Tight color matching
  • Silky smooth long focus throws for precise focus control
  • Non-rotating front designs facilitates easy use of filters, polarizers, and hoods
  • Apertures are de-clicked for precise, smooth and silent operation
  • Left and right side focusing and aperture scales let you work from either side
  • Industry standard 0.8MOD gearing with uniform DSX and DS series focus and aperture gear placement enable fast lens changes when using follow focus devices
  • High Refractive Index, Extra Low Dispersion, Aspherical and Hybrid Aspherical elements are utilized to reduce aberrations, and produce clear, and vibrant images

ADDITIONAL ROKINON CINE DSX LENS FEATURES

  • A new compact and sleek design with a matte black finish
  • Rounded nine blade apertures that deliver even smoother circular bokeh
  • Enhanced lens markings with focal lengths visible from the sides of the lens
  • Two year warranty
  • Available in Canon RF mount
  • The focusing gear is designed wider and feels more comfortable when gripped for focus pulling by hand
  • Weather sealed lens mounts protect the most vulnerable gap between the lens and camera mount

    User Manual Download

    Product 24mm T1.5
    Maximum T-Stop T1.5
    Optical Construction 13 Elements in 12 Groups
    Negative Size 24 x 36 mm
    Angle of View Full Frame (1:1x) 84.1°
    Super 35 65.3°
    APS-C (1:1.5x) 61.3°
    APS-C (1:1.6x) 58.0°
    MFT (1:2x) 47.6°
    Minimum Focusing Distance (∞ ~) 0.25m 0.82 ft
    Filter Size (mm) 77mm
    Diaphragm Blades 9
    Angle Focus Angle 139°
    Aperture Angle  48°
    Weather Sealing Nikon F No
    Others Yes
    Size Canon EF 84.0 x 97.1 mm 3.31 x 3.82 in
    Canon RF 84.0 x 121.1 mm 3.31 x 4.77 in
    Sony E 84.0 x 123.1 mm 3.31 x 4.85 in
    Nikon F 84.0 x 94.6 mm 3.31 x 3.72 in
    Fuji X 84.0 x 123.4 mm 3.31 x 4.86 in
    MFT 84.0 x 121.9 mm 3.31 x 4.80 in
    Weight Canon EF 597.8 g 1.32 lb
    Canon RF 662.6 g 1.46 lb
    Sony E 649.0 g 1.43 lb
    Nikon F 587.0 g 1.29 lb
    Fuji X 640.0 g 1.41 lb
    MFT 636.0 g 1.40 lb
    Gear Ring
    Position
    Module A B C D Focus
    Diameter
    Aperture Diameter
    Canon EF Sony E Nikon F Fuji X MFT Canon EF Others
    Length 0.8 mm 10 mm 4 mm 46.8 mm 10.5 mm 36.5 mm 8 mm 36.8 mm 35.3 mm 73.6 mm 70.4 mm 73.6 mm
    Model: DSX24-C
    UPC: 0-84438-76686-8
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 21.0oz (598g)
    Length: 3.82" (97.1mm)
    Model: DSX24-RF
    UPC: 0-84438-76699-8
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 23.4oz (663g)
    Length: 4.77" (121.1mm)
    Model: DSX24-NEX
    UPC: 0-84438-76687-5
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 22.9oz (649g)
    Length: 4.85" (123.1mm)
    Model: DSX24-MFT
    UPC: 0-84438-76688-2
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 22.4oz (636g)
    Length: 4.80" (121.9mm)
    Model: DSX24-N
    UPC: 0-84438-76706-3
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 20.7oz (587g)
    Length: 3.72"/94.6mm
    Model: DSX24-FX
    UPC: 0-84438-76711-7
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 22.6oz (640g)
    Length: 4.86" (123.4mm)

    Canon EF

    Product 24mm T1.5
    Maximum T-Stop T1.5
    Optical Construction 13 Elements in 12 Groups
    Negative Size 24 x 36 mm
    Angle of View Full Frame (1:1x) 84.1°
    Super 35 65.3°
    APS-C (1:1.5x) 61.3°
    APS-C (1:1.6x) 58.0°
    MFT (1:2x) 47.6°
    Minimum Focusing Distance (∞ ~) 0.25m 0.82 ft
    Filter Size (mm) 77mm
    Diaphragm Blades 9
    Angle Focus Angle 139°
    Aperture Angle  48°
    Weather Sealing Nikon F No
    Others Yes
    Size Canon EF 84.0 x 97.1 mm 3.31 x 3.82 in
    Canon RF 84.0 x 121.1 mm 3.31 x 4.77 in
    Sony E 84.0 x 123.1 mm 3.31 x 4.85 in
    Nikon F 84.0 x 94.6 mm 3.31 x 3.72 in
    Fuji X 84.0 x 123.4 mm 3.31 x 4.86 in
    MFT 84.0 x 121.9 mm 3.31 x 4.80 in
    Weight Canon EF 597.8 g 1.32 lb
    Canon RF 662.6 g 1.46 lb
    Sony E 649.0 g 1.43 lb
    Nikon F 587.0 g 1.29 lb
    Fuji X 640.0 g 1.41 lb
    MFT 636.0 g 1.40 lb
    Gear Ring
    Position
    Module A B C D Focus
    Diameter
    Aperture Diameter
    Canon EF Sony E Nikon F Fuji X MFT Canon EF Others
    Length 0.8 mm 10 mm 4 mm 46.8 mm 10.5 mm 36.5 mm 8 mm 36.8 mm 35.3 mm 73.6 mm 70.4 mm 73.6 mm

    Canon EF

    Model: DSX24-C
    UPC: 0-84438-76686-8
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 21.0oz (598g)
    Length: 3.82" (97.1mm)

    Canon RF

    Model: DSX24-RF
    UPC: 0-84438-76699-8
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 23.4oz (663g)
    Length: 4.77" (121.1mm)

    Sony E

    Model: DSX24-NEX
    UPC: 0-84438-76687-5
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 22.9oz (649g)
    Length: 4.85" (123.1mm)

    Micro 4/3

    Model: DSX24-MFT
    UPC: 0-84438-76688-2
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 22.4oz (636g)
    Length: 4.80" (121.9mm)

    Nikon F

    Model: DSX24-N
    UPC: 0-84438-76706-3
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 20.7oz (587g)
    Length: 3.72"/94.6mm

    Fuji X

    Model: DSX24-FX
    UPC: 0-84438-76711-7
    Focal Length: 24mm
    Maximum Aperture: T1.5
    Angle of View: Full Frame (FX) 84.1˚ / Super 35 65.3˚ / APS-C 61.3˚ / Canon APS-C 58.0˚ / MFT 47.6˚
    Optical Construction: 13 Elements in 12 Groups
    Aperture Range: T1.5 to T22
    Diaphragm Blades: 9
    Coating: Ultra Multi-Coating (UMC)
    Minimum Focusing Distance: 9.84" (250mm)
    Filter Size: 77mm
    Lens Hood: Removable Petal Shaped
    Maximum Diameter: 3.31" (84mm)
    Weight: 22.6oz (640g)
    Length: 4.86" (123.4mm)
