$229.00

8mm F3.5 HD Fisheye

+

The 8mm f/3.5 Fisheye Lens with Removable Hood from Rokinon gives you a 167º view with dramatic, exaggerated perspective when used with an APS-C camera, or a powerful circular image floating in the frame when used with a full frame digital camera or 35mm film camera. With hybrid aspherical elements and multi-layer coating, you will produce sharply defined images with a minimum of flare and ghosting. The 8mm lens focuses as close as 12" (30.48 cm) from the lens. This version of the 8mm f/3.8 Fisheye lens comes with a removable lens hood that will offer glare reduction and lens protection, but can be removed to offer an increased and unobstructed angle of view when shooting with full frame digital or 35mm cameras.

Note: Produces a circular, vignette image on full-frame sensors or 35mm film

  • Ultra wide-angle 8mm fisheye lens with exaggerated perspective for dramatic effects
  • Ultra-wide 167º diagonal field-of-view for APS-C size image formats--will produce a rounded image that doesn't cover the entire frame when used with compatible full frame digital cameras or 35mm film cameras
  • Lens is constructed with hybrid aspherical elements for outstanding, sharply defined images
  • Lens features super multi-layer coating to reduce flare and ghost images
  • Lens has a minimum focusing distance of 12" (30.48 cm) for enhanced close-up shots
  • The petal-style lens hood can be removed so as to not interfere with the image when shooting in full frame digital or 35mm film
  • The optical construction of the lens is 10 elements placed in 7 optical groups. Featuring an aspherical hybrid lens and the latest anti-reflective multi-coating (MC) to minimize flare and ghosting.

User Manual Download

Specifications 8mm F3.5 UMC FISH-EYE CS Ⅱ (DIAGONAL FISH-EYE)
Aperture Range F3.5 ~ 22
Optical
Construction
10 ELEMENTS IN 7 GROUPS (1 ASPHERICAL LENS)
Minimum
Focusing Distance
0.3 m (0.98ft)
Filter Size -
Maximum Diameter 77.8mm
Mount Canon EF Nikon F Pentax K Fujifilm X Sony E Micro 4/3
Angle Of View ASP-C 167˚ 180˚ 180˚ 180˚ 180˚ -
FOUR-THIRDS
4/3”
- - - - - 139.3˚
Length (mm) 75.1mm 72.6mm 73.6mm 101.4mm 101.1mm 99.9mm
Weight (g) 440g 410g 415g 515g 450g 440g
Function A / S / M / P mode (NIKON F)

Model: HD8M-C

UPC: 0-84438-76064-4

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 15.6oz (443g)

Length: 3.04" (77.3mm)

Model: HD8M-N

UPC: 0-84438-76065-1

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 14.5oz (411g)

Length: 2.95” (74.8mm)

Model: HD8M-P

UPC: 0-84438-76090-3

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 14.6oz (414g)

Length: 2.98” (75.8mm)

Model: HD8M-NEX

UPC: 0-84438-76111-5

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 16.0oz (453g)

Length: 4.07” (103.3mm)

Model: HD8M-MFT

UPC: 0-84438-76231-0

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 15.9oz (450g)

Length: 4.02” (102.1mm)

Specifications

Specifications 8mm F3.5 UMC FISH-EYE CS Ⅱ (DIAGONAL FISH-EYE)
Aperture Range F3.5 ~ 22
Optical
Construction
10 ELEMENTS IN 7 GROUPS (1 ASPHERICAL LENS)
Minimum
Focusing Distance
0.3 m (0.98ft)
Filter Size -
Maximum Diameter 77.8mm
Mount Canon EF Nikon F Pentax K Fujifilm X Sony E Micro 4/3
Angle Of View ASP-C 167˚ 180˚ 180˚ 180˚ 180˚ -
FOUR-THIRDS
4/3”
- - - - - 139.3˚
Length (mm) 75.1mm 72.6mm 73.6mm 101.4mm 101.1mm 99.9mm
Weight (g) 440g 410g 415g 515g 450g 440g
Function A / S / M / P mode (NIKON F)


Canon EF

Model: HD8M-C

UPC: 0-84438-76064-4

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 15.6oz (443g)

Length: 3.04" (77.3mm)

Nikon F with AE

Model: HD8M-N

UPC: 0-84438-76065-1

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 14.5oz (411g)

Length: 2.95” (74.8mm)

Pentax K

Model: HD8M-P

UPC: 0-84438-76090-3

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 14.6oz (414g)

Length: 2.98” (75.8mm)

Sony E

Model: HD8M-NEX

UPC: 0-84438-76111-5

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 16.0oz (453g)

Length: 4.07” (103.3mm)

Micro 4/3

Model: HD8M-MFT

UPC: 0-84438-76231-0

Focal Length: 8mm

Maximum Aperture: F3.5

Coverage: APS-C/Four Thirds

Optical Construction: 10 Glass Elements In 7 Groups

Aperture Range: F3.5 to F22

Diaphragm Blades: 6

Coating: Ultra Multi-Coating

Minimum Focusing Distance: 11.8” (0.3m)

Filter Size: n/a

Lens Hood: Removable Petal Shaped

Maximum Diameter: 2.95” (75mm)

Weight: 15.9oz (450g)

Length: 4.02” (102.1mm)
